Top-of-the-line performance and class-leading usability.
Device type | Multifunction Printer |
---|---|
Colour or mono | Colour |
Print speed | 60-69 PPM |
Mono output speed (A4 pages per min) | 65 |
Colour output speed (A4 pages per min) | 65 |
Print resolution (dpi) | 1200 x 1200 |
Copy resolution (dpi) | 600 x 600 |
First time to print mono (secs) | 3 |
First time to print colour (secs) | 4 |
Warm up time (secs) | 22 |
Output size | SRA3 to A5, B6 Lengthwise, A6 Lengthwise Thick Paper, Foolscap* (200 × 330mm), 8K, 16K, Long Length Paper (210 × 457.3mm to 297 × 1200mm),* Set by Customer engineer |
Output size max | SRA3 |
Standard paper input tray 1 (sheets) | 500 (A5-A3) |
Standard paper input tray 2 (sheets) | 2x500 (A5 -A3) |
Standard paper input tray 3 (sheets) | 2500 (A4) |
Standard paper input tray 4 (sheets) | 2500 (A5-SRA3) |
Standard paper input tray 5 (sheets) | 3000 (A4) |
Standard Paper Input Bypass Tray (sheets) | 150 (up to SRA3) |
Maximum paper input (sheets) | 6650 |
Paper weight trays (gsm) | (Tray 1/2) 52 - 256 |
Paper Weight Bypass Tray (gsm) | 52 - 300 |
Standard memory (GB) | 4 |
Storage Capacity (Standard) | 250 |
Document feeder (sheets) | 300 |
Weight (kg) | (Approx) 113 |
Dimension W x D x H (mm) | 615 × 768 × 961 |
Dimension inclusions | Dimensions include Automatic Document Feeder (ADF) |
Power requirements (V / Amp / Hz) | 220-240V / 9A / 50-60Hz |
Max power consumption (kW) | 1.6 |
Automatic duplex unit paper weight (gsm) | 52 to 256 gsm |
Automatic duplex unit max sheet size | SRA3 |
Scan type | Full colour scanner |
Scanning speed simplex max | 120 |
Scanning speed duplex max | 240 |
Interface | Ethernet (10BASE-T / 100BASE-TX / 1000BASE-T) |
Protocol | TCP/IP (FTP, SMB, SMTP) |
Dual scan | Yes |
Scan resolution | Push: 200 dpi / 300 dpi / 400 dpi / 600 dpiPull: 100 dpi / 200 dpi / 300 dpi / 400 dpi / 600 dpi |
Output format | TIFF, JPEG, PDF, Compact PDF, XPS, Compact XPS, PPTx, DOCx*, XLSx*, Searchable PDF*, PDF / A*, Linearised PDF *optional |
Main functions | Scan to E-Mail, Scan to FTP, Scan to BOX (HDD), Scan to PC (SMB), Network TWAIN, Scan to WebDAV, Scan to Me, Scan to Home, Scan to USB, Scan to Scan Server, Scan to Web Service (WSD-Scan), Device Profile for Web Services (DPWS) |
Operating system support | Windows Vista(32/64bit) / 7(32/64bit) / 8/8.1 (32/64bit) / Server 2003(32/64bit) / Server 2008(32-64bit) / Server2008 R2(64bit) / Server 2012 R2(64bit) / Mac OS X 10.6 or later / Unix / Linux / Citrix / SAP / AS/400 |
Processor | 1.6 GHz (ARM Coretex Dual Core) |
Supported protocols | TCP / IP, IPX/SPX (NDS support), SMB (NetBEUI), LPD, IPP1.1, SNMP, HTTP |
Memory | (Shared with copier) |
Printer language | PCL6 (Ver. 3.0) Emulation, PCL5e/c Emulation, PostScript 3 Emulation (3016), XPS Ver. 1.0 |
Printer interface | Ethernet (10BASE-T / 100BASE-TX / 1000BASE-T), USB 2.0, USB Host |
