| Device Type | Multifunction Printer |
| Product Category | Production |
| Colour or Mono | Colour |
| Print Speed | 70-90 PPM |
| Mono Output Speed (A4 pages per min) | 71 |
| Colour Output Speed (A4 pages per min) | 71 |
| Print Resolution(dpi) | 1200 x 1200 |
| Copy Resolution (dpi) | 600 x 600 |
| First Time To Print Mono (secs) | 5.9 |
| First Time To Print Colour (secs) | 7.1 |
| Warm Up Time (secs) | 390 |
| Output Size | A5 – SRA3+ |
| Output Size Max | SRA3 |
| Sheet Size PPG Only | < or = SRA3 |
| Monthly Print Volume | 350000 |
| Average Monthly Volume (A4 pages per mth) | 75000 |
| Average Monthly Print Volume | 80-120K |
| Duty Cycle | 350000 |
| Standard Paper Input Tray 1 (Sheets) | 500 |
| Standard Paper Input Tray 2 (Sheets) | 1000 |
| Standard Paper Input High Capacity Feeder | 4630 |
| Maximum Paper Input (sheets) | 7750 |
| Paper Weight Trays (gsm) | 62-300 |
| Paper Weight Multiple Bypass (gsm) | N/A |
| Standard Memory (GB) | 6GB |
| Hard Drive Standard | 1.5 TB |
| Document Feeder (sheets) | Standard |
| Weight (kg) | 291 (main unit only) |
| Dimension W x D x H (mm) | 760 x 1073 x 903 |
| Dimension Inclusions | Dimensions don't include Automatic Document Feeder (ADF) |
| Power Requirements (V / Amp / Hz) | 240 / 20 |
| Max Power Consumption (kW) | 3.7 |
| Energy Star Typical Energy Consumption (kWh/week) | TBA |
| Automatic Duplex Unit Paper Weight (gsm) | 300 gsm |
| Automatic Duplex Unit Max Sheet Size | SRA3 |
| Options Available PPG Only | Production Options |
| Stapling Unit Output | 3000 |
| Folding and Punching Unit Output | FD-503 (1000) |
| Multi GBC Punching Unit Output | GP-501 |
| Stacking Unit Output | LS-506 (5000 sheets) |
| Booklet Making Unit Output | 50 |
| Perfect Binding Output | PB-503 (300 sheets) |
| Main Unit Input | 1500 |
| Paper Feed Unit Input | 4630 |
| Relay Unit Input | RU-509 |
| Scan Type | Full colour scanner |
| Scanning Speed Simplex Max (ipm) | 70 |
| Scanning Speed Duplex Max (ipm) | 70 |
| Interface | Ethernet 10/100/1000 Base-T, IPv6, USB 2.0 |
| Protocol | TCP/IP |
| Scanning Size Max | A3 |
| Scan Resolution | 600 dpi / 400 dpi / 300 dpi / 200 dpi |
| Output Format | PDF, TIFF |
| Main Functions | TWAIN scan, Scan-to-HDD, Scan-to-FTP, Scan-to-SMB, Scan-to-E-mail, Scan formats TIFF (single and multi page), PDF |
| Modem Type | 0 |
| Transmission Speed | 0 |
| Scanning Speed | 0 |
| Number of Stored Destinations | 0 |
| Number of One Touch Destinations | 0 |
| Number of Group Destinations | 0 |
| Operating System Support | Windows® 7 / 2000 / XP / Vista™, Macintosh® OSX or higher |
| Processor | (Intel® Core2 Duo) 3.0 |
| Supported Protocols | TCP/IP (LPR, RAW socket), IPX/SPX (NDS, Bindery), NetBEUI, IPP, Ether Talk |
| Memory | 6GB |
| Printer Language | PCL5E/XL (PCL6) / Adobe PostScript (PS3019) |
| Printer Interface | PDF directprint (PDF Ver.1.7) / TIFF (TIFF Ver.6) direct print/PPML (Ver 2.1) |
