Combines collaborative robot arm with MiR250 AMR for safe, dynamic navigation in busy environments.
Built-in 2D vision system and optional 3D object recognition enable accurate picking, placement, and flexible task execution.
Key features
Performs a wide range of tasks including machine tending, parts handling, and supply delivery to free up human resources.
Drag-and-drop, block-based interface lets any user deploy or modify robot tasks quickly, with no programming experience.
Combines collaborative robot arm with MiR250 AMR for safe, dynamic navigation in busy environments.
Built-in 2D vision system and optional 3D object recognition enable accurate picking, placement, and flexible task execution.
Performs a wide range of tasks including machine tending, parts handling, and supply delivery to free up human resources.
Drag-and-drop, block-based interface lets any user deploy or modify robot tasks quickly, with no programming experience.
Other features
• Reduces downtime with continuous 24/7 machine tending
• Minimises strain from repetitive manual tasks
• Addresses labour shortages with fast, flexible automation
• Modular design with mounting plate for easy tool change
• Easily deployable across workflows with ER-Ability software
• Web-based control accessible via phone, tablet, or PC
• Fast calibration with high precision using markers or templates
Specifications
| Device type | Autonomous Mobile Robot |
|---|---|
| Category | MiR |
| Weight (kg) | 161 – 174 |
| Dimension Excluding UR Arm (W x D x H) | 580 x 800 x 840 |
| Warranty | 1 year standard |
| Payload Capacity | 186 kg |
| Cobot Arm Options & Payload | UR5e (5 kg), UR10e (12.5 kg), UR16e (16 kg) |
| AMR Platform Options | MiR250 / MiR250 ESD |
| Robotics max speed | 2.0 m/s (7.2 Km/h) |
| Running Time | Up to 4.5 h (100% - 10%) |
| Battery Charging Time | 20-80% in 40 min |
| Daily Utilisation | Up to 20 h |
