Lift, transport, and deliver pallets automatically without manual input.
Securely transports up to 1250 kg with MiR1350 or 500 kg with MiR600.
Key features
Handles multiple pallet formats including 40" x 48" (1m x 1.2m) for wide application use.
Stable lifting and movement reduces strain injuries and workplace incidents.
Lift, transport, and deliver pallets automatically without manual input.
Securely transports up to 1250 kg with MiR1350 or 500 kg with MiR600.
Handles multiple pallet formats including 40" x 48" (1m x 1.2m) for wide application use.
Stable lifting and movement reduces strain injuries and workplace incidents.
Other features
• Eliminates the need for forklifts and manual pallet jacks
• Reliable pallet pick-up from MiR Pallet Rack or floor positions
• Operates safely in dynamic environments with people and obstacles
• Increases throughput with transport speeds up to 2 m/s
• Scales easily across facilities with minimal infrastructure changes
• Frees employees for higher-value tasks
Specifications
| Device type | AMR Add On |
|---|---|
| Category | MiR |
| Dimension W x D x H (mm) | 910 x 1304 x 94 mm (lowered position)/910 x 1304 x 156 mm (lifted position) |
| Lifting Height | 60 mm |
| Pallet Dimensions | Supported with Lift Pallet Rack: 1 016 x 1 219 mm | 40 x 48 in. Can be used for different pallet dimensions. |
| Warranty | 1 year standard |
| Payload Capacity | Up to 500 kg (for MiR600)/Up to 1250 kg (for MiR1350) |
| Running Time | Up to 10.5 h |
| IP Rating | IP52 |
| Safety Standards | ISO 3691-4 (except Clause 4.4, 4.5, 4.9.4, 5.1, 5.2, 6 and Annex A), ISO 13849, ISO 12100, ISO 13850 |
| AMR Top Module | Pallet Lift |
