Built to meet ISO 3691-4 safety standards with reliable obstacle avoidance and safe navigation.
IP52 rating protects against dust and water, enabling performance in demanding environments.
Key features
Transports payloads up to 600 kg at speeds up to 2 m/s for fast material flow.
Works seamlessly with MiR Pallet Lift and Shelf Lift for automated pickup and delivery.
Built to meet ISO 3691-4 safety standards with reliable obstacle avoidance and safe navigation.
IP52 rating protects against dust and water, enabling performance in demanding environments.
Transports payloads up to 600 kg at speeds up to 2 m/s for fast material flow.
Works seamlessly with MiR Pallet Lift and Shelf Lift for automated pickup and delivery.
Other features
• Enables 24/7 operation and reduced reliance on manual labour
• Compact and agile design for navigating tight spaces and busy areas
• Compatible with MiR Fleet for coordinated multi-robot operations
• Supports multiple top modules for flexible logistics use cases
• Reduces operational risks and improves workplace safety
Specifications
| Device type | Autonomous Mobile Robot |
|---|---|
| Category | MiR |
| Weight (kg) | 240 |
| Dimension W x D x H (mm) | 910 x 1350 x 322 |
| Power requirements (V / Amp / Hz) | 48 V / 35 A |
| Interface | API based Web interface |
| Warranty | 1 year standard |
| Payload Capacity | 600 kg |
| Robotics max speed | 2.0 m/s (7.2 Km/h) |
| Battery Charging Time | 10–90% in 45 min |
| Running Time | Up to 8.33 h (with max payload), up to 10.75 h (with no payload) |
| Robotics communication | Wi-Fi, Bluetooth, Ethernet |
| Ingress Protection | IP52 |
| EMC | EN61000-6-4 |
| Safety Standards | ISO 13849-1, ISO 3691-4 (except Clause 4.4, 4.9.4, 5.1, 5.2, 6, and Annex A), ISO 12100, ISO 13850, ITSDF B56-5, RIA R15.08-1 |
