100 ppm A4 / 53 ppm SRA3 colour
Large Range of flexible inline finishing options including the TU-510 option for trimming, creasing and perforation and other options for perfect binding, booklet saddle stitching, folding and auto ring bind finishing.
15,150 sheets maximum
Key features
1,800,000
3600 (Equivalent) x 2400 dpi x 8-bit
Enhanced Simitri® V toner that gives superb print quality and an offset matte finish
100 ppm A4 / 53 ppm SRA3 colour
Large Range of flexible inline finishing options including the TU-510 option for trimming, creasing and perforation and other options for perfect binding, booklet saddle stitching, folding and auto ring bind finishing.
15,150 sheets maximum
1,800,000
3600 (Equivalent) x 2400 dpi x 8-bit
Enhanced Simitri® V toner that gives superb print quality and an offset matte finish
Key Point Intelligence AP C1700 Production Run Test
Auto Quality Adjustment
Auto Quality Adjustment is one of our unique functions of the Intelligent Quality Optimisation Unit IQ-501/IQ-601. The IQ unit scans and measures the quality confirmation charts printed from the AccurioPress print engine and AQA automatically performs self-diagnosis, correction, and repair of the Image Quality, creating increased production time, reducing print wastage and enabling less skilled operation.
Additionally, Auto Quality Adjustment enables our service and support team to proactively understand possible issues as image reports generated by AQA are able available for the team to analyse and identify what parts are required to facilitate an image quality repair.
Specifications
| Device type | Digital Colour Press |
|---|---|
| Category | High speed colour |
| Colour or Mono | Colour |
| Print speed | 91-100 PPM |
| Mono output speed (A4 pages per min) | 110 |
| Colour output speed (A4 pages per min) | 100 |
| Print resolution (dpi) | 2400 x 3600 equivalent dpi x 8-bit |
| Copy resolution (dpi) | 600 x 600 |
| Warm up time (secs) | 390 seconds or less |
| Output size | 330.2 x 487.7mm |
| Output Size (max) | 330.2 x 900mm (Duplex) 330.2 x 1300 ( Simplex) |
| Sheet size PPG only | < or = SRA3 |
| Average monthly volume (A4 pages per month) | 133300 |
| Average monthly print volume | 133300 |
| Duty cycle | 1,800,000 (max in Q zone) |
| Standard paper input tray 1 (sheets) | 1000 |
| Standard Paper Input High Capacity Feeder (A4) | 4630 |
| Maximum paper input (sheets) | 15150 |
| Paper weight trays (gsm) | 52-400 |
| Standard memory (GB) | 8GB |
| Document feeder (sheets) | 300 (optional PF-713) |
| Weight (kg) | 335 (approx. (main unit only)) |
| Dimension W x D x H (mm) | 800 x 1,138 x 1,041 |
| Dimension inclusions | Main Unit Only |
| Power requirements (V / Amp / Hz) | 220V to 240V, 25A |
| Max power consumption (kW) | 6 |
| Automatic duplex unit paper weight (gsm) | 400 gsm |
| Automatic duplex unit max sheet size | 330.2 x 900mm |
| Options available PPG only | Production Options |
| Stapling unit output | 3000 sheets |
| Folding & punching unit output | 1000 (FD-503 Output Tray) |
| Multi GBC punching unit output | GBC G2/G3 |
| Stacking unit output | 6000 (LS-507) |
| Booklet making unit output | 50 sheets (SD-513) |
| Perfect binding output | 300 sheets (PB-503) |
| Scan type | Full colour scanner |
| Scanning speed simplex max | 140 |
